CD Automation REVO C EXTENDED 2PH User Manual page 45

REVO C
2PH from 1100A to 2100A
Parameter Name
Pb Power
Set the gain for the main loop. A larger
value yields a larger adjustment for a
given deviation
Ti Power
Set how aggressively the integral part
of the control algorithm acts. A larger
settings yields a larger adjustment for
a given deviation over a given time
HB Sense
Set the threshold of resistance that
activates the Heater Break alarm. This
setting is in percentage of the nominal
load resistance
HB Delay
Set a delay between when the
resistance drops below the value set
for a heater break sensitivity and when
the heater break alarm is indicated.
This set increments of 50mSec
Logging
Enable or disable data logging on the
internal SD card
Parameter Name
Log Period
Set how often data is logged
Description
Option
Off
On
DEFAULT: Off
Description
Default
10%
50
100%
50
(2,5 sec)
0
Value
0
1
0
Default
5 sec
45
User's manual
Modbus
Range Unit
Address
0 to 255 % 26
0 to 255 27
0 to 100.0 % 29
0 to 255
(0 to 12,75 28
sec)
139
Modbus
Range Unit
Address
0 to 255 sec 70
Par.
Type
Read
Write
Read
Write
Read
Write
Read
Write
Read
Write
Par.
Type
Read
Write
