REVO C
2PH from 1100A to 2100A
8.7 Fan Supply For Each Phase (MX1 – MX2)
Terminal
Description
15
Fan supply voltage (230V standard – 115 option)
16
Fan supply voltage (230V standard – 115 option)
MX
1-2
8.8 Thermal Switch For Each Phase (MX1 – MX2)
Terminal
Description
13
PT2 Thermal Switch
14
PT2 Thermal Switch
MX
1-2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
33
User's manual
FAN
Pt2
