REVO C
2PH from 1100A to 2100A
9.4.6 Monitoring Menu
This section describes each item on the monitoring menu. Use this menu to view the states of digital input,
values of analog input and information about the power controller such as serial number and software version.
The password to access this menu is 0.
Parameter Name
FUSES
Indicate the state of the fuses
Parameter Name
Dig In 1
Indicate the state of the signal to digital input 1
Parameter Name
Dig In 2
Indicate the state of the signal to digital input 2
Parameter Name
FAN
Indicate the state of the fan
Parameter Name
Enable
Indicate whether or not the power controller is enabled. The
enable signal must be on for the unit to output power to the load
Description
Option Value
Off
0
On
1
Description
Option Value
Off
0
On
1
Description
Option Value
Off
0
On
1
Description
Option Value
Off
0
On
1
Description
Option Value
Off
0
On
1
52
User's manual
Modbus Par.
Address Type
Read
13 bit7
Only
Modbus Par.
Address Type
Read
13 bit8
Only
Modbus Par.
Address Type
Read
13 bit9
Only
Modbus Par.
Address Type
Read
13 bit12
Only
Modbus Par.
Address Type
Read
14 bit2
Only
