Configure An Ipv4 Network Interface For The Modem - Digi Connect IT Mini User Manual

Configure the Connect IT Mini
Setting
Enable
Gateway/Netmask
5. Click Save or Apply.

Configure an IPv4 network interface for the modem

You can configure an IPv4 network interface.
1. Log in to manage the Connect IT.
2. Access the Modem
3. Expand the IPv4 section.
4. Configure the settings.
Setting
Enable
Metric
Weight
Digi Connect IT® Mini User Guide
Description
Select Enable to enable a custom gateway for this
network interface.
The gateway address and netmask to use for this
network interface. If either the gateway address or
the netmaks is all 0's, it is not overridden. For
example, 0.0.0.0/32 will operate as normal using the
network-provided gateway IP, but with a /32
netmask.
section.
Description
Select Enable to enable an IPv4 network interface.
The priority of routes associated with the network
interface. If there are multiple active routes that
match a destination, then the route with the lowest
metric will be used.
Default: 3
Minimum: 0
Maximum: 65535
The relative weight of default routes associated with
this network interface. If there are multiple active
default routes with the same metric, then
connections will be load-balanced between the
default routes in proportion to their weight.
Default: 10
Minimum: 1
Maximum: 65535
Configure a modem
33
