Configure the Connect IT Mini
1.
Log in to your Remote Manager
2. Click Try Remote Manager 3.0 preview in the top right of the screen.
3. Click Devices in the left pane.
4. Select the device you want to update.
5. In the toolbar, click Actions > Update Firmware. The Update Firmware pane displays.
6. From the list box, select the appropriate firmware option.
The most current firmware file.
n
Upload Firmware File: Select this option if you want to use a firmware file other than
n
the most current file. If you choose this option, you should
firmware to your
7. Click Update to immediately update the firmware.
Download the Connect IT firmware to your PC
1. Go to www.digi.com/support.
2. Scroll down to the Support Downloads section.
3. Click Firmware Updates.
4. In the Filter the list box, enter Connect IT. As you type, matches display.
5. Click Connect IT.
6. From the Firmware Updates section, select the version you want to download. The file is
downloaded to a folder on your computer. Make a note of the folder path and name.
Configure authentication methods
You can configure a list of the authentication methods to use when authenticating access to services
on the Connect IT. The methods are attempted in the list order until the first successful
authentication result is returned. A user fails authentication when no method succeeds.
1.
Log in
to manage the Connect IT.
2.
Access the Configuration > Authentication
3. Expand the Methods section. One method is included by default. The Local users option is
selected by default.
4. You can add additional methods.
a. Click Add or +. The new row is immediately added to the list of methods.
b. From the Method list box, select the method that you want to use for
Digi Connect IT® Mini User Guide
account.
PC.
authentication:
Local users: Authenticate using the users defined with the configuration.
n
TACACS+: Authenticate using an external TACACS+ server. If you choose this
n
option, make sure you have configured an external TACACS+ server, in
5.
Configure authentication methods
Download the Connect IT
screen.
Step
18
