Configure The Network - Digi Connect IT Mini User Manual

Configure the Connect IT Mini
Setting
Weight
Management priority
MTU
Active recovery
5. Click Save or Apply.

Configure the network

You can configure the network for the Connect IT.
1. Log in to manage the Connect IT.
2. Access the Configuration > Network
3. Each sub-section enables you to configure a different network type. Expand the sub-section
and complete the fields in each of the sections. To display information about what you should
enter in each field, hover over the field name or click the down arrow and then Help next to
each field.
Digi Connect IT® Mini User Guide
Description
The relative weight of default routes associated with
this network interface. If there are multiple active
default routes with the same metric, then
connections will be load-balanced between the
default routes in proportion to their weight.
Default: 10
Minimum: 1
Maximum: 65535
The management priority assigned to this interface.
An interface that is up and has the highest
management priority will have its address reported
as the preferred contact address for central
management and direct device access.
Default: 0
Minimum: 0
Maximum: 1000
Specify a desirable Maximum Transmission Unit
(MTU) for this interface. If this is a non-static (DHCP)
interface, the lower MTU value of the one offered by
the DHCP and the one specified will be in effect.
Default: 1500
Minimum: 576
Maximum: 65535
Active recovery performs regular network tests to
determine if working connections can be made to
remote targets. The network tests available are ping
tests, HTTP/HTTPS tests, and DNS tests. This
interface's default route will be disabled when the
connectivity tests fail, allowing other interfaces with
lower metrics to take precedence.
screen.

Configure the network

35
