Work with the web UI (web user interface)
Local web user interface: Enter a name for the item and then click Add.
n
For example, to add a group: In the Group field, enter a name for the group. Click Add.
Remote Manager: Click the + button, name the item, and then click OK.
n
For example, to add a group: Click the + button. Enter a name for the group and click OK.

Access the Terminal screen

Follow the appropriate process to access the Terminal screen, in which you can use CLI commands to
turn the power to an outlet off and on.
Local web user interface: Click Terminal in the left pane.
n
Remote Manager
n
a. Log in to Remote Manager.
b. Click Try Remote Manager 3.0 preview in the top right of the screen.
c. Click Devices in the left pane.
d. Double-click on the device you want to configure.
e. From the toolbar, click Console.

Access help

To display information about what you should enter in each field, hover over the field name or click the
down arrow and then Help next to each field.

Save your changes

You should save your changes.
Local web user interface: Click Save at the bottom of the screen.
n
Remote Manager: Click Apply at the top of the screen.
n

Log in to the Connect IT local web user interface

You can log in to your Connect IT Mini using the local web user interface on the device. To be able to
access the local web user interface, your PC and the Connect IT must be connected by an Ethernet
cable.
Note When connected to your site network, your Connect IT attempts to use DHCP to establish a
connection and obtain an IP address. If a DHCP server is operating on the site network then the
device will receive an IP address configuration from the local network. You can also access the device
using the IP address provided in the DHCP connection.
1. Connect your PC to the Connect IT with an Ethernet cable.
a. Connect one end of an Ethernet cable to your computer.
b. Connect the other end of the Ethernet cable to the ETH Ethernet port on the
2. Open a web browser on your PC.
Digi Connect IT® Mini User Guide
Connect IT Mini.
Access the Terminal screen
49
