Device Overview; Dimensions - Bender ISOMETER iso1685D Series Manual

Insulation monitoring device for unearthed ac, ac/dc and dc power supplies it systems up to ac 1000 v/dc 1500 v or ac 200 v/dc 3000 v
Hide thumbs
Table of Contents

Advertisement

4. Device overview

4.1 Dimensions

5,2 mm
iso1685
®
ISOMETER
PGH ON
106 mm
39,8 mm
40,75 mm
55,7 mm
51 mm
368 mm
383 mm
401,5 mm
iso1685DP_D00272_03_M_XXEN/08.2017
13
