4. Device overview
4.1 Dimensions
Enclosure iso685...-device familiy – dimensions in mm
11
Device overview
4.2 Device variants
iso685(W)-D...
The iso685 variant features a high-resolution graphic LC display and
operating controls for direct operation of the device functions.
isoxx685(W)-D...
It cannot be combined with an FP200.
iso685(W)-S...
Device version iso685-S-P features neither a display nor operating
controls. It can only be used in combination with the FP200W and is
isoxx685(W)-S...
operated via this front panel.
iso685-x_D00022_08_M_XXEN/02.2019
