Wiring the TX3-NSL-8M Main Controller Board

The TX3-NSL-8M NSL Main Controller Board has both ribbon cable sockets
and screw terminals.
Attention: High voltages are present on this board during the ringing of suite
Figure 43 shows the general layout of the TX3-NSL-8M Main Controller board
components.
TX3-NSL-8M Relay Control Unit
Figure 43. TX3-NSL-8M Main Controller Board
5.3.1 Connectors
USB. Computer connection for firmware download.
P1 and P2. Not used.
P3. Not used.
