To install the Touch Screen Kiosk base plate
1.
2.
3.
Figure 8.
32 TX3 Telephone Access System Installation and Operation Manual
LT-969 Copyright 2019
Find a suitable location for the Kiosk next to the building entrance and
above the building electrical and communications conduit.
Remove the door from the Kiosk.
Remove the 4 bolts from the reinforcement bracket, as shown in figure 8
Reinforcement Bracket
Bolts (x4)
Reinforcement Bracket with bolts
