Figure 11.
6.
Figure 12. Base Plate Mounting Holes
34
TX3 Telephone Access System Installation and Operation Manual
LT-969
Copyright 2019
The 12 Kiosk mounting holes in the base plate are shown in figure 11.
Kiosk Mounting Holes
Using the Kiosk base plate as a template, trace an opening in the floor for
the cutout and mark the 4 base plate mounting hole locations as shown in
figure 12. Ensure that the base plate is aligned with the electrical conduit.
Base plate mounting holes (x4)
Kiosk Mounting Holes (x12)
Cutout
Cutout
Enclosure Installation
Version 5.4
