Technical Support; Fault Table - Gechter HKPL-DS Translation Of The Original Operating Manual

10.1

Technical Support

Please refer to the "Identification" chapter for how to contact the
customer service of Gechter GmbH!
10.1.1

Fault table

Error description
The nominal press force
is not reached
Air is escaping from the
press when it is at a
standstill
The press sled moves
laterally or jams
The press sled moves
downward too slowly
The press sled moves
downward too slowly /
too quickly
The hand lever only
moves upwards with dif-
ficulty
–
HKPL-DS Translation of the original operating manual
Faults
Cause
The seal kit is worn
The compressed air
does not have the
correct operating
pressure
The press sled does
not have enough
play
Leaks
Compressed air in-
take too high
The press sled has
too much or too little
play
The sound absorber
is dirty
Wrong setting of the
exhaust air throttle
(delay valve)
Return spring broken
The press sled does
not have enough
play
96
Remedial measure
Have the press in-
spected by GECHTER
GmbH or request a
technician
Adjust the com-
pressed air with the
maintenance unit
pressure regulator
Adjust the adjust-
ment gib
Have the press in-
spected by GECHTER
GmbH or request a
technician
Check the mainte-
nance unit setting
Adjust the adjust-
ment gib
Replace the sound
absorber
Adjust the exhaust
air throttle
Install a new return
spring
Adjust the adjust-
ment gib
10
Personnel
Gechter GmbH
Operator
Technically
trained per-
sonnel
Gechter GmbH
Technically
trained per-
sonnel
Technically
trained per-
sonnel
Technically
trained per-
sonnel
Technically
trained per-
sonnel
Technically
trained per-
sonnel
Technically
trained per-
sonnel
