Test Record - Tektronix AWG5200 Series Technical Reference

Performance tests

Test record

AWG5200 series performance test record
AWG Model:
AWG Serial Number:
Temperature:
Date of Calibration:
Performance test
Analog Amplitude Accuracy
DC High BW Output Path
AWG5202, AWG5204, AWG5208
Ch 1 +
Ch 2 +
AWG5204, AWG5208
Ch 3 +
64
Photocopy the test record pages and use them to record the performance test
results for your AWG.
Amplitude
25 mV
p-p
100 mV
p-p
200 mV
p-p
500 mV
p-p
1 V
p-p
1.5 V
p-p
Amplitude
25 mV
p-p
100 mV
p-p
200 mV
p-p
500 mV
p-p
1 V
p-p
1.5 V
p-p
Amplitude
25 mV
p-p
100 mV
p-p
200 mV
p-p
500 mV
p-p
1 V
p-p
1.5 V
p-p
Certificate Number:
RH %:
Technician:
Minimum
23.75 mV
98 mV
196 mV
480 mV
980 mV
1.47 V
23.75 mV
98 mV
196 mV
480 mV
980 mV
1.47 V
23.75 mV
98 mV
196 mV
480 mV
980 mV
1.47 V
AWG5200 Series Technical Reference
Test result Maximum
26.25 mV
102 mV
204 mV
520 mV
1.02 V
1.53 V
26.25 mV
102 mV
204 mV
520 mV
1.02 V
1.53 V
26.25 mV
102 mV
204 mV
520 mV
1.02 V
1.53 V
