AWG5200 Series Technical Reference
15. Repeat steps 7 through 13 until all channels are checked, modifying the
instructions for the channel number under test.
16. Press the AWG front panel All Outputs Off button (or click All Outputs Off
on the Home screen) to disable the outputs (front panel light on).
17. Disconnect the test setup.
Performance tests
57
