Table 7: Signal output characteristics (cont.)
Characteristics
AC DC bias accuracy
(warranted)
Output path
AC Direct
AC Amplified
(Option AC)
Analog bandwidth
Output path
DC High BW
DC High BW
(Option DC)
DC High Volt
(Option HV)
AC Direct
AC Amplified
(Option AC)
Rise/fall time
Output path
DC High BW
DC High BW
(Option DC)
DC High Volt
(Option HV)
Step response aberrations
Output path
DC High BW
DC High BW
(Option DC)
DC High Volt
(Option HV)
AWG5200 Series Technical Reference
Description
±(2% of bias + 20 mV); into an open circuit (zero load current).
±(2% of bias + 20 mV); into an open circuit (zero load current).
Analog bandwidth is measured with the ideal sin(x)/x response curve of the DAC
mathematically removed from the measured data.
At 750 mV single ended:
pp
DC - 2 GHz (–3 dB bandwidth).
DC - 4 GHz (–6 dB bandwidth).
At 1.5 V single ended:
pp
DC - 1.3 GHz (–3 dB bandwidth).
The analog bandwidth degrades as the amplitude is increased beyond 750 mV.
At 2 V single-ended:
pp
DC – 370 MHz (–3 dB bandwidth).
At 4 V single-ended:
pp
DC – 200 MHz (–3 dB bandwidth).
10 MHz - 2 GHz (–3 dB bandwidth).
10 MHz - 4 GHz (–6 dB bandwidth).
10 MHz - 2 GHz (–3 dB bandwidth).
10 MHz - 4 GHz (–6 dB bandwidth).
Rise and fall times only apply to DC output paths.
< 115 ps at 750 mV single ended.
pp
< 180 ps at 1.5 V single ended.
pp
< 1.3 ns, at 5 V single-ended.
pp
< 1.1 ns, at 4 V single-ended.
pp
< 0.8 ns, at 3 V single-ended.
pp
< 0.6 ns, at 2 V single-ended.
pp
Step response aberrations only apply to DC output paths.
< 16% , at 750 mV single ended.
pp pp
< 16% , at 1.5 V single ended.
pp pp
< 10% , at 5 V single ended.
pp pp
