Table 7: Signal Output Characteristics - Tektronix AWG5200 Series Technical Reference

Table 6: Analog output skew (cont.)
Characteristics
Skew adjustment resolution
Skew stability between channels
Sync out to channel
Channel to channel
Phase adjustment
Range
Resolution

Table 7: Signal output characteristics

Characteristics
Connector type
Number of outputs
DAC resolution
Type of outputs
Output path
DC High BW
DC High Volt
(Option HV)
AC Direct
AC Amplified
(Option AC)
ON/OFF control
Output impedance
AWG5200 Series Technical Reference
Description
250 fs
< ±0.5 ps/ °C
< ±0.5 ps/ °C (±0.18 ps/ °C @ 1 GHz)
Used to adjust skew between all channels in an instrument relative to another instrument.
-8,640° to +8,640° of the DAC clock.
1° of the DAC clock.
Description
2 SMA connectors per channel.
AWG5202: 2.
AWG5204: 4.
AWG5208: 8.
16, 15, 14, 13 or 12 bits.
Enabling markers degrades resolution.
16-bit mode: 0 markers available.
15-bit mode: 1 marker, M1.
14-bit mode: 2 markers, M1, M2.
13-bit mode: 3 markers, M1, M2, M3.
12-bit mode: 4 markers, M1, M2, M3, M4.
(+) and (–) complementary (differential).
Includes a variable gain, high bandwidth, DC coupled amplifier in the signal path.
(+) and (–) complementary (differential).
An additional amplifier adds high amplitude with reduced bandwidth.
Single ended output from the (+) connector.
A direct connection to the DAC output including a balun to reduce common mode distortion.
The AC Direct path offers the lowest noise and distortion performance.
Single ended output from the (+) connector.
Includes an amplified path and a passive variable attenuator path to provide a large output
amplitude range.
Independent control for each analog output channel.
50 Ω
Specifications
5
