Table 8: Harmonic distortion (DC High BW output path)
DC High BW output path
At 500 mV
pp
2nd harmonic
(Differential or with a balun)
10 MHz to 1 GHz
1 GHz to 1.5 GHz
1.5 GHz to 4 GHz
2nd harmonic
10 MHz to 500 MHz
500 MHz to 1 GHz
1 GHz to 4 GHz
3rd harmonic
10 MHz to 750 MHz
750 MHz to 1.2 GHz
1.2 GHz to 2 GHz
At 1.5 V
pp
2nd harmonic
(Differential or with a balun)
10 MHz to 500 MHz
500 MHz to 1 GHz
1 GHz to 4 GHz
2nd harmonic
10 MHz to 500 MHz
500 MHz to 1 GHz
1 GHz to 4 GHz
3rd harmonic
10 MHz to 500 MHz
500 MHz to 1 GHz
1 GHz to 4 GHz
Table 9: Harmonic distortion (DC High Voltage output path)
DC High Voltage output path
At 500 mV
pp
2nd harmonic
(Differential or with a balun)
10 MHz to 1 GHz
1 GHz to 1.5 GHz
1.5 GHz to 4 GHz
AWG5200 Series Technical Reference
< –65 dBc
< –60 dBc
< –50 dBc
< –55 dBc
< –48 dBc
< –30 dBc
< –65 dBc
< –50 dBc
< –40 dBc
< –55 dBc
< –45 dBc
< –35 dBc
< –38 dBc
< –25 dBc
< –20 dBc
< –33 dBc
< –25 dBc
< –20 dBc
< –65 dBc
< –60 dBc
< –50 dBc
Specifications
11
