Tektronix AWG5200 Series Technical Reference page 21

Table 7: Signal output characteristics (cont.)
Characteristics
Amplitude range
Output path
DC High BW
DC High BW
(with Option DC
Amplified)
DC High Volt
(Option HV)
AC Direct
AC Amplified
(Option AC)
Amplitude adjustment resolution
Output paths
DC High BW
DC High Volt
(Option HV)
AC Direct
AC Amplified
(Option AC)
DC amplitude accuracy
Output path
DC High BW
DC High Volt
(Option HV)
AC amplitude accuracy
Output path
AC Direct
AC Amplified
(Option AC)
AWG5200 Series Technical Reference
Description
25 mV to 750 mV into 50 Ω single-ended.
p-p p-p
50 mV to 1.5 V into 100 Ω differential.
p-p p-p
25 mV to 1.5 V into 50 Ω single-ended.
p-p p-p
50 mV to 3.0 V into 100 Ω differential.
p-p p-p
10 mV to 5 V into 50 Ω single-ended.
p-p p-p
20 mV to 10.0 V into 100 Ω differential.
p-p p-p
–17 dBm to –5 dBm.
10 MHz to 3.5 GHz.
–85 dBm to 10 dBm (10 MHz to 3.5 GHz.)
–50 dBm to 10 dBm (3.5 GHz to 5 GHz.)
Amplitude accuracy and flatness degrades at frequencies beyond 3.5 GHz and below –50 dBm
output amplitude. It is not recommended to operate in this region.
1 mVpp or 0.1 dB.
1 mVpp or 0.1 dB.
0.1 dB
0.1 dB
Within ±5 °C of internal self calibration temperature.
Amplitude < 100 mV: ±5% of amplitude
Amplitude 100 mV to 1.5 V: ±2% of amplitude
Amplitude < 160 mV: ±5% of amplitude
Amplitude 160 mV to 5 V: ±2% of amplitude
0.5 dB at 100 MHz (0 °C to 45 °C)
1 dB at 100 MHz (45 °C to 50 °C)
0.5 dB at 100 MHz (0 °C to 45 °C)
1 dB at 100 MHz (45 °C to 50 °C)
Specifications
7
