Network Port Specifications
C.1.6 AUI Cable
The following specifications show AUI cable requirements for the
EPIM-A and EPIM-X:

AUI Cable

The AUI cable must be IEEE 802.3 type cable.
Length
The AUI Cable must not exceed 50 meters (165 feet) in length. If 28 AWG
thin office drop AUI cable is used, then the maximum cable length is
limited to 15.24 meters (50 feet).
Grounding
The connector shell of the EPIM-A and the EPIM-X are connected to
ground.
C.2 NETWORK PORT SPECIFICATIONS
The MicroMMAC-22E and MicroMMAC-24E network ports use
shielded RJ45 connectors that support both STP and UTP cabling. The
MicroMMAC-32E and MicroMMAC-34E use RJ71 connectors for
network connections. The following sections provide specifications for
each MicroMMAC model.
MicroMMAC Installation Guide Page C-7
