Chapter 2: Controls and Indicators

2.3.2 Saved Alarm Messages

Saved Alarm messages describe events that occur within the
MicroMMAC or on the network. Table 2-2 shows each Saved Alarm
message. To view Saved Alarm messages, perform the following steps:
1. Press the Display button for five seconds and then release to view the
first Saved Alarm message in the message queue.
2. Press and immediately release the Display button to scroll through
each subsequent message.
If the Display button is not pressed again for 10 seconds, the LCD
defaults to the product name.
Displayed Messages
No Messages in Queue
Port xxxxxx
Segmented
Port xxxxxx
UnSegmented
Port xxxxxx
Link Established
Port xxxxxx
Not Linked
EPIM-x
Inserted
EPIM-x
Removed
EPIM-x
Security Violation
CableRedun Fail
Port EPIM-x
CableRedun Enable
Port EPIM-x
Port xxxxxx
Disabled
Page 2-4
Table 2-2 Saved Alarm Messages
Comments
No Alarm messages in queue. This is the
default setting.
Displays segmentation status of network ports
1–24, EPIM-1 or EPIM-2.
Displays segmentation status of network ports
1–24, EPIM-1, or EPIM-2.
Displays link status of network ports 1–24,
EPIM-1, EPIM-2, or BRIM-1.
Displays link status of network ports 1–24,
EPIM-1, EPIM-2, or BRIM-1.
Displays installation status of EPIM-1 or
EPIM-2.
Displays installation status of EPIM-1 or
EPIM-2.
Indicates unauthorized access attempt at
EPIM-1 or EPIM-2.
Indicates failure of redundant link at EPIM-1 or
EPIM-2.
Indicates redundant link enabled.
EPIM-1 or EPIM-2.
Indicates network ports 1–24, EPIM-1, or
EPIM-2 disabled.
MicroMMAC Installation Guide
