Cabletron Systems MicroMMAC-24E Installation Manual page 67

Appendix B: EPIM Specifications
Parameter
Transmitter Peak
Wave Length
Spectral Width
Rise Time
Fall Time
Duty Cycle
Bit Error Rate
The transmitter power levels and receive sensitivity levels listed in
Table B-1 represent Peak Power Levels after optical overshoot. You must
use a Peak Power Meter to correctly compare the above values to those
you measure on any particular port. If you measure Power Levels with an
Average Power Meter, you must add 3 dBm to the measurement to
correctly compare those measured values to the values listed above (e.g.,
-29.5 dBm peak = -32.5 dBm average).
Page B-4
Table B-2 EPIM-F3 Specifications
Typical Value
1300 nm
60 nm
3.0 ns
2.5 ns
50.1%
Better than 10
Minimum
1270 nm
–
2.7 ns
2.2 ns
49.6%
-10
MicroMMAC Installation Guide
Maximum
1330 nm
100 nm
5.0 ns
5.0 ns
50.7%
