To install the replacement FLASH SIMM, refer to Figure 3-4 and perform
the following steps:
1. With the SIMM notch positioned as shown in Figure 3-4, gently insert
the FLASH SIMM into the SIMM connector.
2. Carefully rock the FLASH SIMM back towards the connector clips
until the clips snap into place and secure the FLASH SIMM.
NOTCH
CONNECTOR CLIP
MicroMMAC Installation Guide
2
Figure 3-4 Installing a FLASH SIMM
Upgrading the FLASH SIMM
1
CONNECTOR
SIMM
CONNECTOR CLIP
1742-33
Page 3-7
