Chapter 2: Controls and Indicators

2.2 TURNING THE MicroMMAC ON AND OFF

The MicroMMAC is NOT equipped with a Power ON/OFF
NOTE
switch.
To power-on the MicroMMAC, perform the following steps:
1. Plug the power cord into the power cord connector on the back panel
of the MicroMMAC.
2. Plug the other end of the power cord into a grounded wall outlet.
3. Verify that the PWR LED is on, indicating that the MicroMMAC is
receiving power. After the MicroMMAC runs a self test, the CPU
LED blinks green indicating normal operation. If the LED remains
red, the processor is faulty; contact Cabletron Systems Technical
Support.
To power-off the MicroMMAC, disconnect the power cord from the
power outlet.

2.3 USING THE LCD AND LCD DISPLAY BUTTON

The LCD provides information about the operation of the MicroMMAC
and network activity. Four types of messages appear on the LCD:
• Static System Messages
• Saved Alarm Messages
• Unsaved Initialization Messages
• Saved System Messages
The following sections describe each type of LCD message and provide
instructions for displaying them.
Page 2-2 MicroMMAC Installation Guide
