2.3.1 Static System Messages

Static System messages provide MicroMMAC configuration information.
Table 2-1 lists each message. To view Static System messages, perform
the following steps:
1. Press and immediately release the Display button to view the first
Static System Message in the queue.
2. Press and release the Display button to display each subsequent
message.
If the Display button is not pressed again for ten seconds, the LCD
defaults to the product name.
Displayed Messages
IP Address
xxx.xxx.xxx.xxx
MAC Address
00001dxxxxxx
RAM Image
Rev. xx.xx.xx
Boot PROM
Rev. xx.xx.xx
Flash Programmed
xx Times
COM 1 Port
Baud Rate xxxxx
COM 1 Port
Function xxxxx
COM 2 Port Baud Rate
xxxxx
COM 2 Port
Function xxxxxx
MicroMMAC Installation Guide
Using the LCD and LCD DISPLAY Button
Table 2-1 Static System Messages
Comments
Displays the MicroMMAC's IP address. The IP
address can be changed through Local
Management.
Displays the MicroMMAC's MAC address (this
address is also called the physical address).
Displays the revision number of the image
currently executing in FLASH.
Displays the revision number of the internal
Boot PROM.
Displays the number of times FLASH has been
programmed.
Displays the Baud Rate for the COM 1 port. The
default setting is AUTO because the
MicroMMAC uses Auto-Baud detection.
Displays the current function of the COM 1 Port
(N/A, UPS, LM).
Displays the baud rate for the COM 2 port. The
default setting is AUTO because the
MicroMMAC uses Auto-Baud detection.
Displays the current function of the COM 2 Port
(N/A, UPS, LM).
Page 2-3
