Chapter 2: Jumpers and Connectors

LVDS Inverter Connector

Connector type: 1x7 7-pin header, 1.25mm pitch
Connector location: J6
1 7
Pin Definition
1 5V
3 12V
5 INV_GND
7 BKLTEN
MH2 INV_GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 12V
4 BKLTCTRL
6 INV_GND
MH1 INV_GND

USB Connector

Connector type: 1x4 4-pin header, 1.25mm pitch
Connector location: J4
1 4
Pin Definition
1 5V
3 USB2P4
MH1 GND
24
Pin Definition
2 USB2N4
4 GND
MH2 GND
