Chapter 2: Jumpers and Connectors

LVDS Channel A Connector

Connector type: 2x10 20-pin header, 1.25mm pitch
Connector location: CN9
1
2
Pin Definition
1 VCC5_VDD
3 VCC3_VDD
5 LVDSA_DAT0N
7 LVDSA_DAT0P
9 GND
11 LVDSA_DAT2N
13 LVDSA_DAT2P
15 GND
17 LVDSA_DAT3N
19 LVDSA_DAT3P
MH1 GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
19
20
Pin Definition
2 VCC5_VDD
4 LVDSA_DAT1N
6 LVDSA_DAT1P
8 VCC3_VDD
10 LVDSA_CLK1N
12 LVDSA_CLK1P
14 GND
16 12V
18 12V
20 GND
MH2 GND

LVDS Channel B Connector

Connector type: 2x10 20-pin header, 1.25mm pitch
Connector location: CN11
1
2
Pin Definition
1 VCC5_VDD
3 VCC3_VDD
5 LVDSB_DAT4N
7 LVDSB_DAT4P
9 GND
11 LVDSB_DAT6N
13 LVDSB_DAT6P
15 GND
17 LVDSB_DAT7N
19 LVDSB_DAT7P
MH1 GND
19
19
20
Pin Definition
2 VCC5_VDD
4 LVDSB_DAT5N
6 LVDS_DAT5P
8 VCC3_VDD
10 LVDSB_CLK2N
12 LVDSB_CLK2P
14 GND
16 12V
18 12V
20 GND
MH2 GND
