Chapter 1: Product Introduction

Rear

DVI-I LAN 1 to LAN 4
Ports
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
USB 2.0 24V DC Input
USB 3.0 COM
DVI-I Port
Used to connect a DVI-I interface monitor.
LAN 1 to LAN 4 Ports
Used to connect the system to a local area network.
USB 3.0 Ports
Used to connect the system with USB 3.0/2.0 devices.
USB 2.0 Ports
Used to connect the system with USB 2.0/1.1 devices.
COM Port
Serial DB9 port used to connect RS232/422/485 compatible devices.
24V DC Input
Used to plug a DC power cord.
