Chapter 2: Jumpers and Connectors

PWR/HDD LED Connector

Connector type: 1x4 4-pin header, 1.25mm pitch
Connector location: J1
1 4
Pin Definition
1 PWRLED#
3 HDD_LED#
MH1 GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 PWRLED
4 HDD_LED
MH2 GND

USB Connector

Connector type: 1x4 4-pin header, 1.25mm pitch
Connector location: J2
1 4
Pin Definition
1 5VSB
3 USB2P6
MH1 GND
20
Pin Definition
2 USB2N6
4 GND
MH2 GND
