ZeitNet Proprietary MIB
The object identifier for hostConfigAddr is:
iso.org.dod.internet.private.enterprise.zeitnet.znProducts.znManagedObjects.znIpAtm.znIpAtmClient.znIpAtmClien
tLisTable.znIpAtmClientLisEntry.znIpAtmClientLisSubnetMask or 1.3.6.1.4.1.1295.2.200.1.1.1.3. The entire
ZeitNet Cabletron SmartCell 6A000 MIB subtree looks like Figure B-3.
znManagedObjects
Figure B-3 ZeitNet Cabletron 6A000 MIB object identifier example
B.2.2

Proprietary MIB Functions

The following is a list of the ZeitNet proprietary MIBs and their general functions:
•
znleMIB: SmartCell 6A000 specific VLAN related activity
•
znIpAtmClentMIB: SmartCell 6A000 implementation of IP over ATM
•
znCommonMIB: SmartCell 6A000 specific common objects such as enabling AutoDetect, UNI,
Signaling, Community Strings, and Traps
•
znIispMIB: SmartCell 6A000 specific IISP
•
switchMIB: SmartCell 6A000 specific switch ports, configuration, thresholds, queues, and timers
Note For explanations of the function of each MIB object, consult the description fields
within the respective MIB files.
To use the provided SmartCell 6A000 MIBs, your NMS application must be
Note
capable of compiling both SNMPv1 and SNMPv2 MIBs.
Appendix B-4 SmartCell 6A000 User Guide
Label from the ZeitNet root to
this point is 1.3.6.1.4.1.1295
2
znIpATM (1295.2.200)
znCommon (1295.2.300)
znTrap (1295.2.301)
znCommon (1295.2.300)
znIisp (1295.2.3333)
znLeMIB (1295.4)
SmartCell 6A000 and SNMP
