Zeitnet Proprietary Mib; Internet Mib Hierarchy - Cabletron Systems SmartCell 6A000 User Manual

ZeitNet Proprietary MIB

Figure B-1 Internet MIB Hierarchy
B.2 ZEITNET PROPRIETARY MIB
The private ZeitNet MIB is represented by the object identifier 1.3.6.1.4.1.1295, or
iso.org.dod.internet.private.enterprise.zeitnet. The ZeitNet MIB includes the following subtree object identifiers:
•
znManagedObjects (1295.2)
•
znleMIB (1295.4)
•
znIpAtmClent (1295.200.1)
•
znCommon (1295.2.300)
•
znLecUpAlarm (1295.2.301.4)
•
znIispMIB (1295.2.3333.6)
•
switchMIB (1295.200.1)
Appendix B-2 SmartCell 6A000 User Guide
root
CCITT ISO
0 1
org
3
DOD
6
internet
1
directory mgmt
1 2
MIB
1
SmartCell 6A000 and SNMP
t t
joint
ISO/CCITT
2
experimental private
3
4
Label from the root to
this point is 1.3.6.1.2.1
