Specifications
Table A-8
Management Protocol
A.3.5

CPU Serial Port Pin-Out Descriptions

Table A-9
RJ-45
Pin Color
1 Blue
4 Red
5 Green
Table A-10 RJ-45 to DB-25 Adapter (Terminal Adapter)
RJ-45
Pin Color
4 Red
1 Blue
5 Green
Appendix A-10 SmartCell 6A000 User Guide
Management Standards and Specifications (Continued)
MIBs supported
AToM2 MIB (pre-standard)
LANE MIB (ATM Forum)
PNNI MIB (ATM Forum)
UNI 3.0/3.1 ILMI MIB (ATM Forum)
IP over ATM MIB (pre-standard)
IISP MIB
SmartCell 6A000 Switch MIB
RJ-45 to DB-9 Adapter (PC Serial Port Adapter)
DB-9
Pin Description
2 Receive
3 Transmit
5 Ground
DB-25
Pin Description
2 Transmit
3 Receive
7 Ground
Features and Specifications
