Cabletron Systems SmartSwitch 2H22 Supplemental Manual page 19

\
Device Configuration Menu
Password
Device
Menu
Device
Statistics
Menu
Network Tools
Notes:
* Refer to the SmartTrunk User's Guide for the screen hierarchy.
** This screen is only available on repeater devices (2E43-51, 2E43-51R,
2H23-50R, and 2H33-37R).
Indicates the part of the hierarchy that changed.
Figure 1-1 802.1D Switching Mode, LM Screen Hierarchy
Local Management Supplement
General Configuration
SNMP Community Names Configuration
SNMP Traps Configuration
System Resources Information
Flash Download Configuration
Port Configuration
Menu
802.1 Configuration Menu
Switch Configuration
Switch Statistics
Interface Statistics
RMON Statistics
** Repeater Statistics
2E43-51 or
2E43-51R only
Repeater Level
Security Configuration
Port Level
Security Configuration
Accessing Local Management
Ethernet Full
Duplex Configuration
High Speed
Interface
Configuration
* SmartTrunk
Configuration
Port Redirect Configuration/
Redirect Configuration Menu
Broadcast
Suppression
Configuration
** Repeater
Configuration Menu
2H23-50R or
2H33-37R only
Fast
Ethernet
Interfaces
HSIM
Port Redirect
Configuration
VLAN Redirect
Configuration
Repeater Port
Configuration
Module Level
Security Configuration
Port Level
Security Configuration
