Parts List, Removal & Replacement - Signode MCD-710 Operation, Parts And Safety Manual

PARTS LIST
KEY QTY PART # DESCRIPTION
1 1 016120 Roll pin, 1/4 x 2-1/4
2 2 008597 O-ring, SAE 214
3 1 014620 Idler shaft
4 2 008596 O-ring, SAE 111
5 1 014739 Thrust bearing
6 1 014621 Idler gear
6A 3 014685 Roller clutch
7 1 014622 Idler pinion
8 1 014704 Sleeve bearing
9 2 014714 Belleville washer
10 1 014601 Vibrator gear
11 1 053043 Cam shaft cover
12 1 053054 Oil seal, C/R #10153
13 1 091863 O-ring, SAE 227
14 25 004238 Lockwasher, #10
15 4 004618 SHCS, #10-24 x 5/8
16 1 014679 Bearing, N/D Z99R16
17 14 002187 Lockwasher, 1/4
18 13 009041 SHCS, 1/4-20 x 3/4
19 1 053453 Kick tab
20 1 053454 Vibrator cam
21 2 014678 Truarc, #N5000-268
22 2 014681 Bearing
23 2 014623 Vibrator clutch
24 2 014677 Truarc, #5100-156
25 1 014720 Key
26 1 008378 Key
27 2 014676 Truarc, #5133-98
28 1 053040 Cam shaft
29 1 014609 Inner race assembly, for
MCD-310 only
1 042776 Inner race assembly, for
MCD-710 only
1 009884 Inner race assembly, for
MCD-510 only.
(Tenax strap only.)
Requires Std Vibrator
29A 1 014705 Sleeve bearing
31 2 014682 Bearing
32 3 014813 Spring
33 1 014608 Cam shaft cover
33A A/R 006697 Shims
34 2 014810 Roll pin, 1/4 x 1 1/4
35 2 043855 Roll pin, 5/32 x 1 1/4
36 28 009041 SHCS, 1/4-20 x 3/4
37 4 007146 SHCS, 1/4-20 x 1 1/4
38 1 014724 Sheave assembly
39 1 280720 Back clutch cover
39A 4 280721 Back cover shim
40 8 009050 SHFS, #10-24 x 5/8
41 1 053052 O-ring, SAE 135
42 1 053055 Oil seal
43 2 053059 Bearing
44 2 053042 Seal pinion stop
45 2 014807 Pinion stop spring
KEY QTY PART # DESCRIPTION
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
68A
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
96
97
179
16
For Parts & Service 1-877-862-6699
1 014642 Right clutch pinion
1 014624 Tensioner Clutch
1 014672 Left clutch pinion
1 071636 Key
1 053039 Clutch shaft
1 053045 Front clutch cover
1 008546 O-ring, SAE 225
2 014728 Bearing, N/D Z99502
1 014811 Flexloc nut
1 014655 Spring spacer
8 014730 Belleville washer
2 014641 Clutch disc
1 014658 Slip clutch pinion
1 014657 Chain sprocket
1 015310 Feed shaft
2 008584 O-ring, SAE 113
1 053057 Oil seal, C/R #12384
1 014727 Bearing, N/D Z99604
1 053053 O-ring, SAE 139
1 053048 Feedwheel cover
1 053046 Tension shaft plug
1 014660 Tension shaft plug
1 014659 Tension gear
2 014729 Roller clutch
1 014808 Chain
1 014666 Sprocket assembly
1 014663 Tension shaft
1 053041 Sprocket spacer
1 053056 Oil seal
1 053060 Bearing, N/D Z499604
1 007027 O-ring, SAE 141
1 053047 Tension shaft cover
2 072108 Flexloc nut
2 014722 Bearing
1 014639 Fork pin
1 014638 Knuckle pin
1 014633 Knuckle
2 053063 E-ring, X5133-31
1 014637 Fork
1 014643 Fork pivot pin
2 014652 Vibrator shaft keeper
3 008922 Pipe plug
1 053450 Gear housing
1 014634 Pusher
1 009719 Spring (Std. Tension)
1 014881 Spring (Low Tension)
1 014640 Tension regulator
4 014726 Tension stop ring
1 014721 Quad ring SAE 222
1 008361 Hand wheel
2 008853 FHSCS, 5/16-18 x 5/8
6 009397 SHCS, #10-24 x 1/2
