Signode MCD-710 Operation, Parts And Safety Manual page 18

PARTS LIST, CONTINUED
WELDING ASSEMBLY
KEY QTY PART # DESCRIPTION
14 2 004238 Lockwasher, #10
98 1 280724 Edge guide, Std.
1 014451 Edge guide, Short
99 1 280723 Strap guide
99A 1 280722 Side guide spacer
100 6 005319 Hex locknut, 1/4
101 4 009042 SHCS, 1/4-20 x 1
102 1 077871 Cutter
102A A/R 043512 Shim
103 1 016614 Gripper, Std.
1 014455 Gripper, Short
104 1 432501 Right side guide
104A 1 432502 Side guide spacer
105 1 432508 Left side guide
106 3 004174 SHCS, #10-24 x 7/8
107 4 023766 Truarc, #5133-25
108 2 016631 Gripper pin
109 1 016619 Grip yoke ass'y, Std.
1 014456 Grip yoke ass'y, Short
110 1 016630 Sealer housing, Std.
1 014471 Sealer housing, Short
111 1 042777 Grip segment, Std.
1 014453 Grip segment, Short
112 1 077874 Right grip carriage
113 1 016620 Left grip carriage, Std.
1 053455 Left grip carriage, Short
114 1 077872 Right grip segment
115 2 014809 Roll pin, 3/32 x 1
116 1 014610 Anchor plate
117 2 015304 Wedge pin
118 8 014616 Link
119 4 014617 Link pin
120 1 014618 Toggle plate
121 1 070445 Grease fitting
121A 1 007568 Pipe plug, 1/8"
125 1 014653 Vibrator shaft
126 1 260418 Face gate, Std.
1 260419 Face gate, Short
127 1 014647 Face gate support, Std.
1 014463 Face gate support, Short
130 1 014816 Gate spring
131 2 014782 Truarc, #5133-18
132 1 016635 Gate pivot pin
133 2 015145 Flexloc nut, 3/8-16
134 1 014740 Vibrator ass'y, Std.
1 014883 Vibrator ass'y, Short
134A 2 004549 Roll pin
134B 1 014776 Bushing
KEY QTY PART # DESCRIPTION
134C 1
135
136
137
138
139
140
141
142
143
144
145
146
147
148
182
18
For Parts & Service 1-877-862-6699
014644 Vibrator insert, Std.
1 014452 Vibrator insert, Short
1 014680 Bearing, N/D Z499503
1 016633 Release pin, Std.
1 014882 Release pin, Short
1 013630 HHCS, 1/4-20 x 1 1/4
1 014804 Spring
1 163356 Spring, for use with Tenax
strap only.
4 013626 SHCS, 5/16-18 x 1 1/4
2 014781 Needle roller
2 014668 Guide roller
2 014812 Spring, standard vibrator
2 160574 Spring, Std., for use with
Tenax strap only.
Requires a Std. Vibrator.
2 014940 Spring, short vibrator
1 014667 Cam roller spacer
2 014686 Bearing, McGill
#CF-3/4-SB
1 013533 Truarc, #5100-66
1 014683 Bearing, INAC #NK 12/16
1 008598 Truarc, #5100-66
1 016636 Vibrator eccentric
2 023099 BHCS, #10-24 x 3/8
