COVERS, SIGNS AND DISPENSER BRACKETS
KEY QTY PART # DESCRIPTION
221 3 014980 HHCS, 3/8-16 x 3
222 1 168607 Electrical name plate
223 1 185803 Warning sign
231 2 177816 Warning sign
232 1 055962 Instruction plate
236 1 286206 Warning sign
273 3 076482 Drive screw, #2 x 5/16
274 2 071129 Logo
275 1 014960 Right cover, Std.
1 056076 Right cover, Short
276 1 014950 Left cover
277 1 286207 Safety sign
278 2 185803 BHCS, 5/16-18 x 5/8
279 4 016638 FHSS, 5/16-18 x 5/8
282 1 014905 Base assembly
283 2 002844 HHCS, 3/8-16 x 1 1/4
284 2 014999 Dispenser bracket assembly
285A 4 014828 Roll pin, 7/16 x 1
286 1 014490 Pulley arm assembly
1 059213 Pulley arm assembly, 90° right angle
288 1 081618 Nameplate (MCD-710)
1 176963 Nameplate (MCD-510)
28
For Parts & Service 1-877-862-6699
