A.1.1 mini PCI Express Connector Design Recommendations
The MiniCore is mounted on the Interface Board via a mini PCI Express connector and a corre-
sponding locking latch connector. These are offered by manufacturers as a matched set, although
in some cases different manufacturer's parts may be interchangeable.
mended parts for the mini PCI Express connector and the locking latch connector used for the Interface
Board. (All measurements are in inches followed by millimeters enclosed in parentheses.)
Table A-3. Interface Board Connector-Related Parts
Connector Part
mini PCI Express Connector
Latch Connector
Figure A-3 shows a footprint for the SMT connectors in
Figure A-3. PCB SMT Footprint for Pinrex and FOXCONN Connectors
MiniCore RCM5700/RCM6700 User's Manual
Manufacturer Part Number
Pinrex 984-63-052202
FOXCONN AS0B226S68K-7F
Table A-3.
digi.com
Table A-3 lists the recom-
Rabbit Store Part
Number
498-0090
498-0091
52
