Secure Embedded Web Application Kit 2.0
The Secure Embedded Web Application Kit allows you to develop a secure embedded Web interface for
your embedded systems. The Application Kit is based on the RCM4300 RabbitCore module, which fea-
tures built-in Ethernet, a swappable flash memory device, and an optional A/D converter.
Application Kit Contents
®
RabbbitCore
RCM4300 module.
•
Prototyping Board.
•
miniSD™
512 MB
Card with SD Card adapter
•
• Universal AC adapter, 12 V DC, 1 A (includes Canada/Japan/U.S., Australia/N.Z., U.K., and
European style plugs) .
USB programming cable with 10-pin header.
•
Cat. 5 Ethernet crossover cable.
•
10-pin header to DB9 serial cable.
•
Secure Embedded Web Application Kit CD including Dynamic C
•
Embedded Security Pack, and sample programs and information related to the Secure Embedded Web
Application Kit — with complete product documentation on disk.
Getting Started instructions.
•
Plastic and metal standoffs with 4-40 screws and washers.
•
A bag of accessory parts for use on the Prototyping Board.
•
Rabbit 4000 Processor Easy Reference poster.
•
Registration card.
•
Visit our online Rabbit store at
the latest information on peripherals and accessories that
are available for the RCM4300 RabbitCore modules.
Rabbit, RabbitCore, Dynamic C, and Digi are registered trademarks of Digi International Inc.
SD is a trademark of the SD Card Association.
www.rabbit.com/store/
for
®
, FAT File System, RabbitWeb, Rabbit
Installing Dynamic C
Insert the CD from the Application Kit in your
PC's CD-ROM drive. If the installation does
not auto-start, run the setup.exe program
in the root directory of the Dynamic C CD.
®
Advertisement
Related Manuals for Rabbit RCM4300
Summary of Contents for Rabbit RCM4300
- Page 1 The Secure Embedded Web Application Kit allows you to develop a secure embedded Web interface for your embedded systems. The Application Kit is based on the RCM4300 RabbitCore module, which fea- tures built-in Ethernet, a swappable flash memory device, and an optional A/D converter.
- Page 2 RCM4300 module during debugging. Connect the 10-pin connector of the programming cable labeled PROG to header J1 on the RCM4300 as shown in Figure 3. Be sure to orient the marked (usually red) edge of the cable towards pin 1 of the connector. (Do not use...
- Page 3 Once all the other connections have been made, you can connect power to the Prototyping Board. First, prepare the AC adapter for the country where it will be used by selecting the plug. The RCM4300 Development Kit presently includes Canada/Japan/U.S., Australia/N.Z., U.K., and European style plugs.
- Page 4 Application Note AN417, Secure Embedded Web Application Kit 2.0. The source code for the sample programs is provided to allow you to modify them for your own use. The RCM4300 User's Manual on the Dynamic C CD also provides complete hardware reference information and describes the software function calls for the RCM4300 RabbitCore modules and the Prototyping Board.
