ADUX1020-EVAL-SDP User Guide
EVALUATION BOARD SOFTWARE QUICK START PROCEDURES
INSTALLING THE
OPTICAL GESTURE EVALUATION
TOOL
Download the
Optical Gesture Evaluation Tool
from the
ADUX1020-EVAL-SDP
loaded software folder, run the enclosed ADI_OpticalGesture_
EvaluationTool.exe file, and follow the prompts for installing
the
Optical Gesture Evaluation Tool
further information, follow the full installation guide included
with the
Optical Gesture Evaluation Tool
downloaded folder.
Figure 2.
Optical Gesture Evaluation Tool
To start the
Optical Gesture Evaluation Tool
navigate to the ADI_OpticalGesture_EvaluationTool from the
Start menu and click the ADI_OpticalGesture_EvaluationTool
icon (see Figure 3).
Figure 3. Navigate to Optical Gesture Evaluation Tool from Start Menu
At startup, the
Optical Gesture Evaluation Tool
automatically checks if the installed
Tool
software version is up to date. If there is a newer version
available, the user is prompted to download the newest version.
EVALUATION BOARD USB CONNECTION
Ensure the provided
EVAL-SDP-CB1Z
ADUX1020-EVAL-MCM
connect together and connect to a PC
via the USB cable included with the evaluation kit. After the
Optical Gesture Evaluation Tool application opens, click File >
Connect (see Figure 4) and select SDP ASIC Bridge (Debug).
The
Optical Gesture Evaluation Tool
ADUX1020-EVAL-SDP
kit is connected.
software package
product page. Unzip the down-
software (see Figure 2). For
software in the
Setup
application,
application
Optical Gesture Evaluation
controller board and
then acknowledges the
CONFIGURING THE
EVALUATION KIT
Before operating the
jumper across Header J7 on the ADUX1020-EVAL-MCM. If
using the
ADUX1020-EVALZ-LED
the jumper from Header J7.
To operate the
ADUX1020
Load Cfg. Select the 004_ADUX1020_StandardR1.dcfg file
and click Open (see Figure 5).
Figure 5. Loading the Configuration File
Next, click View > Off-Chip Analysis and Gesture View to open
the Graph XYI tab (see Figure 6). With the evaluation board
positioned so there are no objects around it within at least a 20 cm
radius, click the Channel Auto Calibration button to calibrate the
ADUX1020-EVAL-SDP
then acknowledges if calibration is successful.
Rev. A | Page 3 of 8
Figure 4. SDP ASIC Connection
ADUX1020-EVAL-SDP
ADUX1020-EVAL-SDP
kit, connect any
daughterboard, disconnect
in gesture detect mode, click File >
kit. The
Optical Gesture Evaluation Tool
UG1022
