EVAL-AD5600PMDZ

EVALUATION BOARD SOFTWARE QUICK START PROCEDURES

INSTALLING THE SOFTWARE

The EVAL-AD5600PMDZ uses the
desktop software application that allows the evaluation and
control of multiple evaluation systems.
The ACE installer installs the necessary
Microsoft® .NET Framework 4 by default. The
available for download from the EVAL-AD5600PMDZ product
page, and must be installed before connecting the
the USB port of the PC to ensure that the
when it connects to the PC. For full instructions on how to install
and use this software, see the
Devices website.
After the installation is finished, the EVAL-AD5600PMDZ icon
appears when the ACE software is opened.
User Guide
ACE evaluation software, a
SDP drivers and the
ACE software is
SDP board to
SDP board is recognized
ACE software page on the Analog
Figure 2. Board View of the EVAL-AD5600PMDZ
Figure 3. Chip Block Diagram of the

INITIAL SETUP

To set up the EVAL-AD5600PMDZ, take the following steps:
1. Connect the evaluation boards as shown in Figure 1, and
then connect the USB cable between the
the PC.
2. Run the ACE
appear in the attached hardware pane of the Start tab.
3. Double click the board icon to open the board view shown
in Figure 2.
4. Double click the AD5600 icon in Figure 2 to access the
chip block diagram. This view provides a basic representation
of the functionality of the board. The main function blocks
of the board are labeled in Figure 3.
AD5600
Rev. 0 | Page 3 of 8
SDP-B
application. The EVAL-AD5600PMDZ icon
UG-1584
board and
