ADDITIONAL EVALUATION BOARDS

HIGH POWER LED DAUGHTERBOARD

The ADUX1020-EVALZ-LED
the standard ADUX1020-EVAL-MCM
functions as a high-power LED driver intended for gesture
recognition at distances greater than 15 cm.
To use the ADUX1020-EVALZ-LED, attach it to the
ADUX1020-EVAL-MCM evaluation board as shown in Figure 9.
The daughter-board connects to the
via five pins, labeled on the daughterboard as GND, GND1,
LEDX, 3.3V, and VLED. These pins on the daughterboard plug
into five similarly spaced test points on the
MCM labeled JL1, JL2, JL3, JL4, and JL5. When connecting the
ADUX1020-EVALZ-LED, ensure Header J7 on the
ADUX1020-EVAL-MCM is not connected, as shown in Figure
9.
is an optional daughterboard for
evaluation board. It
ADUX1020-EVAL-MCM
ADUX1020-EVAL-
Operation and configuration of the
the ADUX1020-EVALZ-LED
instructions listed in the Evaluation Board Software Quick Start
Procedures section.
Figure 9. Connecting the
Rev. A | Page 5 of 8
UG1022
ADUX1020-EVAL-SDP
daughterboard follows the
ADUX1020-EVALZ-LED Daughterboard
with
