Configuring the iPP320 PINpad

1
AccesstheiPP320PINpad's"MENU"screen
a. Ensure that the "INIT REQUIRED" screen is displayed.
b. Quickly press the function keys in the following
sequence: F2, F1, F3, and F4.
c. Do one of the following:
• If the "MENU" screen (shown here) is displayed,
proceed to step 2 (Configure the iPP320 PINpad's
optional settings) below.
• If the "INIT REQUIRED" screen is displayed, repeat
steps 1a-b of this procedure.
2
ConfiguretheiPP320PINpad'soptionalsettings
a. When the "MENU" screen displays, press F2 to scroll
to CONFIGURATION.
b. Press the green key to continue.
c. When the "CONFIGURATION" screen displays,
press F4 (YES).
d. Press the green key to continue.
e. When the "LANGUAGE/LANGUE" menu displays,
select a language type:
• For English, press F1(ENGL).
• For French, press F4(FRAN).
6
U S I N G T H E M E R C H A N T R E S O U R C E C E N T E R : M O N E R I S ® I P P 3 2 0 P I N PA D S E T U P G U I D E
f.

INITREQUIRED

MENU
DISPLAYSTATUS
CONFIGURATION
g.
h.
MENU
DISPLAYSTATUS
CONFIGURATION DISPLAYSTATUS
i.
CONFIGURATION
NO YES
j.
LANGUAGE/LANGUE
ENGL FRAN
k.
ConfiguretheiPP320PINpad'soptionalsettings...continued
When the "CABLE TYPE" menu displays, select a
cable type:
• If you are using a USB cable, simply press the
green key to select USB.
• If you are using a serial cable, press F2 to scroll to
RS232, and then press the green
select it.
When the "QR-CODE" screen displays, press F4 (OFF).
When the "BEEP" screen displays, press F1 (ON).
When the "PED SERIAL NUMBER 61012345" screen
displays, press the green key to continue.
Wait while the iPP320 PINpad reboots.
When the "INIT REQUIRED" screen displays, proceed
to Configuring your Merchant Resource Center com
port setting on page 8.
CABLE TYPE
USB
RS232
key to
QR-CODE
ON OFF
BEEP
ON OFF
PED
SERIALNUMBER
61012345
PINPAD
WILLREBOOT
INFEWSECONDS,
PLEASEWAIT

INITREQUIRED
