1

Introduction

1.1 Overview

ADLINK's DLAP-8000 Series of industrial GPU workstations,
incorporating Intel
five PCIe slot supporting two FHFL PEG cards, one mini-PCIe slot
and single-side access for I/O ports, optimizing easy maintenance
in industrial automation environments. The DLAP-8000 series
supports DDR4 memory for more powerful computing and the
®
Intel
HD Graphics 630 speeds graphics performance. Along with
a versatile I/O array and flexible expansion capacity, the DLAP-
8000 Series fully satisfies all the needs of industrial automation
(IA) with the performance demanded by vision inspection, motion
control, and surveillance applications. Fanless construction not
only overcomes contaminant and noise challenges presented by
harsh IA environments, the elimination of problematic structural
elements that negatively affect MTBF greatly increases lifecycle
expectations for the platform.

1.2 Features

9th Gen Intel® Xeon®, Core™ i7/i5/i3 LGA processors with
workstation C246 chipset
Dual SODIMMs for up to 64GB DDR4 / ECC options
(available on Xeon/i3 SKUs)
Rich I/O: 2x DP++, 1x DVI-I, 3x GbE, 4x COM, 8-ch DI, 8-ch
DO, TPM 2.0
2x USB 3.1 Gen2, 1x USB 3.1 Gen1, 3x USB 2.0
Rich storage: Up to 4 hot swappable 2.5" SATA 6 Gb/s tray
with RAID 0/1/5/10 support, CFast, M.2 2280
Embedded expansion: 1x Mini PCIe, 1x M.2 3042, 2x USIM
Front accessible I/O and adaptive Function Module v.2
option
Introduction
®
Core
i7/i5/i3 and
®
processors, provides
Xeon
DLAP-8000
1
