Leading EDGE COMPUTING
3.1.14
DC Power Input

Table 3-12: Backplane DC Power Input Pin Definition

20

Figure 3-9: DC Power Input

Pin
1
2

Table 3-11: DC Power Input Pin Definition

Figure 3-10: Backplane DC Power Input

Pin
1
2
3
4
Signal
V+ (DC_IN)
V- (DGND)
Signal
V+
V+
V-
V-
System Layout
