3.1.5
PCI Express x4 Slot
One PCI Express x4 (data bus x1) slot supports expansion with
standard PCIe Gen3 cards.
3.1.6
Reset Button
The reset button executes a hard reset for the DLAP-8000.
3.1.7
DisplayPort Connectors
Two DisplayPort connectors on the front panel can connect to
VGA, DVI, HDMI and DisplayPort monitors via DisplayPort to VGA
adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to
HDMI adapter cable and DisplayPort cable.

Figure 3-2: DisplayPort Connector Pin Definition

Pin
1
2
3
4
5
6
7
8
9
10
System Layout
19
20
Signal
Pin
CN_DDPx0+ 11
GND
12
CN_DDPx0-
13
CN_DDPx1+ 14
GND
15
CN_DDPx1-
16
CN_DDPx2+ 17
GND
18
CN_DDPx2-
19
CN_DDPx3+ 20

Table 3-3: DisplayPort Pin Definition

1
2
Signal
GND
CN_DDPx3-
CN_DDPx_AUX_SEL
CN_DDPx_CONFIG2
CN_DDPx_AUX+
GND
CN_DDPx_AUX-
CN_DDPx_HPD
GND
+V3.3_DDPx_PWR_CN
DLAP-8000
13
