Table 3-5: Digital Input/Output Connector Pin Definition; Figure 3-4: Digital Input Circuit - ADLINK Technology DLAP-8000 Series User Manual

High performance 9th generation intel® xeon®/core™ i7/i5/i3 processor edge workstation computer
Table of Contents

Advertisement

Pin
Signal
1
DI0
2
DI1
3
DI2
4
DI3
5
DI4
6
DI5
7
DI6

Table 3-5: Digital Input/Output Connector Pin Definition

System Layout
Pin
Signal
Pin
8
DI7
15
9
GND
16
10
N/C
17
11
N/C
18
12
N/C
19
13
N/C
20
14
N/C
21

Figure 3-4: Digital Input Circuit

Signal
Pin
Signal
N/C
22
N/C
23
N/C
24
GND
25
DO0
26
DO1
DO2
2.2
D
G
S
DLAP-8000
DO3
DO4
DO5
DO6
DO7
15
