System Layout

3.1 Front Panel

The DLAP-8000 Series provides the following front panel access
features.
A
B
DC Power Input
A
DisplayPort x2
B
DVI-D
C
VGA
D
USB 3.1 Type-A x3 (1, 2, 4)
E
Gigabit Ethernet x3
F
USB 2.0 Type-A x3 (3, 5, 6)
G
LED Indicators
H
System Layout
C
D
E
O

Figure 3-1: Front Panel I/O

Table 3-1: Front Panel I/O Legend

F
N
Extend Power Button
I
J Power Button
K Reset Button
L Audio (Mic, Phones/Speaker)
M Digital Input/Output
N CFast
O COM Port x4
DLAP-8000
G H I J K
M
L
11
