ADLINK Technology DLAP-8000 Series User Manual page 14

Leading EDGE COMPUTING
DLAP-800X
Physical
Dimensions 210 (W) x 210 (D) x 350 (H) mm (8.27" x 8.27" x 13.8")
DC mode: 7 kg (15.43 lbs)
Weight
AC mode: 9 kg (19.84 lbs)
Mounting Wall mount
Power Supply
DC Input 24V DC
AC Input Optional: 80-264V AC
Environmental
Operating
Standard: 0°C to 50°C
Temperature
Storage
-40°C to 85°C (-40°F to 185°F) (excluding storage)
Temperature
Humidity approx. 95% @ 40°C (104°F) (non-condensing)
Operating: 3 Grms, 5-500 Hz, 3 axes (w/ SSD/CFast)
Vibration
Operating: 0.3 Grms, 5-500 Hz, 3 axes (w/ HDD)
Shock Operating: 30 G, half sine 11ms duration (w/ SSD/CFast)
ESD Contact +/-4kV, Air +/-8kV
EMC EN61000-6-4/-2, CE & FCC Class A
Safety UL/cUL, CB, CCC
4
DLAP-8001 DLAP-8002 DLAP-8003
Specifications
