Jumper/Switch Summary & Locations - Connect Tech SMARC 2.0 User Manual

Designator
P3 HDMI0
P4 HDMI1
P5 GPIO Header
P6 I2C Header
P7 Mini PCIe Slot 0
P8 Mini PCIe/mSATA Slot 1
P9 +5V Power Input
P10 External RTC Header
P11 System Control Header
P12 RS-232 Serial Header
P13 USB2.0 double stack, ports 0/1
P14 USB3.0 double stack, ports 2/3
P15A GBE0
P15B GBE1
P16 microSD Slot
P17 +5V Fan Header
Jumper/Switch Summary & Locations
Designator
S1 Carrier Control DIP Switch
J1 HDMI0 DDC Level Translation Select Jumper
Document: CTIM-00154
Revision: 0.04
Description
Description
Page 9 of 22
SMARC 2.0 Carrier
Users Guide
www.connecttech.com
Date: 2021-06-18
