Know Your Setu Vfxth; Overview - Matrix SETU VFXTH Quick Start Manual

Thank you for choosing the Matrix SETU VFXTH. Please read the instructions in this Quick Start to
install and operate your SETU VFXTH properly.
This Quick Start is meant to help you install and configure the basic parameters of the system. For
advanced configuration and feature description, please refer the System Manual. To download,
click https://www.matrixtelesol.com/product-manuals.html
You can also view and download the manual by scanning the QR code printed on the Product
Label/Packaging Label.
For product registration and warranty related details, please visit
product-registration-form.html

Overview

SETU VFXTH is available in the following configurations:
Sr.NO. Configuration
1 SETU VFXTH0016
2 SETU VFXTH0024
3 SETU VFXTH0032
4 SETU VFXTH1600*
5 SETU VFXTH3200
6 SETU VFXTH0808
7 SETU VFXTH1616*
* SETU VFXTH1600 and SETU VFXTH1616 has been discontinued. However, software support is still
provided through Jeeves for the users who have already installed it.
Matrix SETU VFXTH Quick Start

Know Your SETU VFXTH

SIP Trunks
16
24
32
16
32
16
32
https://www.matrixcomsec.com/
FXO Ports FXS Ports
0 16
0 24
0 32
16 0
32 0
8 8
16 16
Physical Port Labels
FXO FXS
0 P01-P16
0 P01-P24
0 P01-P32
P01-P16 0
P01-P32 0
P01-P08 P09-P16
P01-P16 P17-P32
